GARMIN STRIKER VIVID 7CV + TRANSDUCER

GARMIN STRIKER VIVID 7CV + TRANSDUCER
FOR SALE AT ACCASTILLAGE DIFFUSION STRASBOURG
PLEASE CONTACT US FOR MORE INFORMATION
☎ 03 88 41 02 41
@ contact@ad-strasbourg.com

• Physical dimensions: 23.5 x 14.0 x 5.8 cm (9.3″ x 5.5″ x 2.3″)
• Weight: 0.8 kg (1.7 lb)
• Water resistance: IPX7
• Touchscreen: No
• Display type: Color WVGA
• Display format (W x H): 15.4 x 8.6 cm; 17.8 cm diagonal (6.1″ x 3.4″; 7″ diagonal)
• Screen resolution (W x H): 800 × 480 pixels
• Mounting options: Flush mount or tilt/swivel bracket
• Buttons: With buttons

Maps and Memory

• Waypoints: 5,000
• Track points: 50,000
• Tracks: 50 recorded tracks
• Routes: 100

Sensors

• GPS: Yes
• Built-in receiver: Yes
• WAAS support: Yes

Optional map support

• Garmin Quickdraw Contours: Yes

Electrical Specifications

• Power supply: 12 to 20 V DC
• Consumption at 12 V DC: 0.67 A
• Maximum consumption at 12 V DC: 1.5 A
• Power consumed: 6.6 W

Sonar Functions and Features

• Sonar display: Yes
• Traditional sonar (dual frequency/beam): Built-in
• ClearVü: Yes
• Supported frequencies:
– Traditional: 50/77/200 kHz CHIRP (mid and high)
– ClearVü: 260/455/800 kHz
• Output power: 500 W (RMS)
• Bottom lock: Yes (displays value from the seabed)
• Water temperature log and graph: Yes

Connections

• 4-pin transducer ports: 1
• Garmin Wi-Fi® network (local connection): Yes

Fish Finder Functions

• Split screen zoom: Yes
• Fish symbol ID: Yes (displays fish with symbols)
• Automatic Sensitivity Technology: Yes (reduces noise, enhances targets)
• Adjustable depth line: Yes (measures depth of submerged objects)
• A-scope: Yes (real-time display of fish passing through the transducer beam)
• Included water temperature sensor: Yes
• Depth shading: Yes

Other Features

• Waypoint marking: Yes
• Course over ground (COG): Yes
• Wireless connectivity: Yes
• Quickdraw contours: Yes
• One 4-pin transducer port
• One SideVü 4-pin transducer port
