DF 20A S/L

SUZUKI DF 20A S/L ENGINE
FOR SALE AT ACCASTILLAGE DIFFUSION STRASBOURG
PLEASE CONTACT US FOR MORE INFORMATION
☎ 03 88 41 02 41
@ contact@ad-strasbourg.com

• Engine type: 4-stroke
• Number of cylinders: 2 inline
• Displacement: 327 cm³
• Engine type: Overhead camshaft, 4 valves
• Fuel supply system: Sequential multi-point fuel injection
• Ignition system: Digital CDI
• Bore x Stroke: 60.4 mm x 57 mm
• Maximum power: 14.7 kW (20 hp)
• Full power operating range: 5,300 - 6,300 rpm
• Alternator: 12V/6A (option on S and L) - 12V/12A (ES, EL, TS, TL, THL)
• Starting system: Manual / Electric (ES, EL, TS, TL, THL)
• Oil capacity: 1 L
• Fuel tank capacity: 12 L
• Model reference: S / L / ES / EL / TS / TL / THL
• Shaft / transom length: 381 mm (S, ES, TS) / 508 mm (L, EL, TL, THL)
• Dry weight (with battery cable, without propeller or oil): 44 kg (S) / 45 kg (L) / 48 kg (ES, TS) / 49 kg (EL, TL, THL)
• Total dry weight: 52.5 kg (S) / 54.5 kg (L) / 55.5 kg (ES, EL, TS, TL, THL)
• Steering: Mechanical remote (TS, TL)
• Engine mount: Flexible damping
• Tilt and trim: Manual / Electric (TS, TL, THL)
• Gear ratio: 2.08:1
• Gear shift: Forward / Neutral / Reverse
• Exhaust: Through the propeller hub
• Aluminum propeller choice: 7 - 11 inches
