Mercury 20

MERCURY F 20 EFI EPT/ELPT ENGINE AVAILABLE AT ACCASTILLAGE DIFFUSION STRASBOURG PLEASE CONTACT US FOR MORE INFORMATION ☎ 03 88 41 02 41 @ contact@ad-strasbourg.com • Power: 20 hp (14.7 kW) • Dry weight: 45 kg • RPM: 5700 - 6200 • Displacement: 351 cc • Number of cylinders: 2 (inline) • Starting: Electric • Intake system: 2 valves per cylinder, SOHC (Single OverHead Camshaft) • Direction: Forward (F) - Neutral (N) - Reverse (R) • Gear ratio: 2.15:1 • Recommended transom height: 508 mm • Engine protection system for operator: SmartCraft Engine Guardian • Alternator (amps/watts): Not specified, but compatible with electrical system • Cooling system: Water cooled with thermostat • Transmission: Forward (F), Neutral (N), Reverse (R) • Available mounts: Standard • Trim system: Electric • Exhaust system: Via propeller • Shallow water drive: Yes • Trim angle for shallow depths: 16° • External fuel tank: 12 L • Bore and stroke: 2.40 x 2.24" / 61 x 57 mm • Ignition: CDI with electronic ignition timing • 4-stroke / 351 cc • Remote control • Available with long shaft • Requires a license • Security cord included • External 12 L tank easy to connect • Oil pressure warning light • Engine protection system: SmartCraft Engine Guardian • Lightweight: only 45 kg • Easy to transport: Large ergonomic carry handle, compact size, accessible fuel valve
