F 8

NEW MERCURY BRAND ENGINE TYPE F8

- F 8 MH/MLH: 3122? - Short or long shaft, Manual start, Tiller
- F 8 EH/ELH: 3742? - Short or long shaft, Electric start, Tiller

4 STROKE, CARBURETED.
SUPPLIED WITH PROPELLER.
5 YEAR WARRANTY.
PRICE EXCLUDING TRANSPORT

HP / kW - 8 / 5.9
Engine type - Inline 2
Displacement (CID/CC) - 12.8 / 208
Maximum RPM - 5000-6000
Fuel induction system - Single overhead camshaft (SOHC) with 2 valves per cylinder
Alternator amperes/watts - 6 A / 76 watts
Recommended fuel - Unleaded 98 gasoline
Recommended oil - Mercury FourStroke 10W-30 oil
Engine protection warning system - Low oil pressure / Over-rev
Start - Manual or electric
Steering - Tiller
Shaft length - 15" / 381 mm - L: 20" / 508 mm
Gear ratio - 2.08:1
Dry weight *Lightest available model - 38 kg
CARB star rating - 3
Bore and stroke - 2.16 x 1.73" / 55 x 44 mm
Ignition - CDI with electronic ignition advance
Fuel system - Carbureted
Cooling system - Water-cooled with thermostat
Direction - F-N-R
Gearcase options - Standard
Trim positions - Ratcheting
Exhaust system - Through propeller
Shallow water drive - Yes
Shallow water trim range (degrees) - 16
Integrated fuel tank (gal / L) - 3.2 / 12
Standard external fuel tank (gal / L) - 3.2 / 12
Color - Phantom Black

Improved features:
The Mercury 8 and 9.9 hp FourStroke outboards include:
- A new three-position choke with no priming button for improved starting, simplified starting procedure, and faster engine warm-up.
- A richer air/fuel mixture at idle for easier starting and better idle quality (tiller models).
- Modified ignition timing to allow anglers to find and maintain an optimal trolling speed.

Command Thrust: Unmatched Power. Longer and incorporating longer components, the Mercury Command Thrust gearcase was specifically designed to provide the power, thrust, and control required for wider and heavier boats.

The Command Thrust difference:
- A 20% larger propeller increases control, especially at low speeds.
- The longer gearcase submerges the propeller deeper underwater, beneath turbulent water. Result: better performance.
- A low gear ratio of 2.42:1 provides the thrust and maneuverability essential for heavy loads.
- An oversized anti-cavitation plate. This oversizing prevents air intake into the propeller, increasing efficiency.

Practical and easy lifting: Lower the tiller to easily raise the outboard in any position, thanks to our exclusive ratchet transom bracket.
