F30 BEHDL

YAMAHAMARINE F30B The Yamaha tiller steer and injection engine!

ENGINE REPOWERING PROMOTION VALID FROM MARCH 7 TO JUNE 10, 2025 - TRADE IN AN ENGINE OVER 10 YEARS OLD TO BENEFIT FROM A SPECIAL OFFER!

TECHNICAL DESCRIPTION:

Engine type: four-stroke
Displacement: 747 cm³
Number of cylinders/configuration: 3/in-line, SOHC
Bore x stroke: 65.0 mm x 75.0 mm
Power at the propeller shaft at mid-range: 22.1 kW at 5,500 rpm
Full throttle rpm range: 5,000 - 6,000 rpm
Lubrication: Wet sump
Electronic fuel injection (EFI)
Ignition/advance: Electronic (CDI)
Starting system: Electric with Prime Start™
Gear ratio: 2.00 (26/13)
Dimensions
Recommended transom height S: 414 mm L: 536 mm
Weight with propeller (kg) F30BEHDL: 102.0 kg, F30BETS: 94.0 kg, F30BETL: 98.0 kg
Separate fuel tank capacity: 25 liters
Oil capacity: 1.7 liters
Additional features
Tiller control (EHD), Remote control (ET + ED) Tiller control (EHD), Remote control (ET)
Power trim and tilt (trim angle) Assisted power trim and tilt (ET), Hydraulic power tilt (ED + EHD) Assisted power trim and tilt (ET), Hydraulic power tilt (EHD)
Alternator 12 V - 17 A with rectifier/regulator 12 V - 17 A with rectifier/regulator
Trim limiter (remote control only) - -
Anti-theft system Y-COP YCOP YCOP
Propeller Optional Optional
Counter rotation propeller model - -
Shallow water drive system Standard Standard
Compatible with Digital Network Gauge II displays (color LCD) - -
Compatible with Digital Network Gauge (Round/Square) displays Optional Optional
Electronic trolling speed control With digital displays or multifunction tiller
With digital displays or multifunction tiller
Dual battery charging system - -
Transmission damper system (SDS) -
