YAMAHA F9.9JMHS

MISTRAL PLAISANCE your YAMAHA dealer in LAVANDOU presents the 9.9hp 4-stroke engine

TRANSPORTABLE ENGINES YAMAHAMARINE F9.9JMHS

YAMAHA F9.9JMHS short shaft
Engine type: four-stroke
Displacement: 212 cm³
Number of cylinders/configuration: 2/in-line, SOHC
Bore x stroke: 56.0 mm x 43.0 mm
Power at propeller shaft at mid-range: 7.3 kW at 5,500 rpm
Full throttle operating range: 5,000 - 6,000 rpm
Lubrication: Wet sump Wet sump
Electronic injection: Carburetor Carburetor
Ignition/advance: Electronic (CDI) Electronic (CDI)
Starting system: Manual (MH), Electric (E) Manual
Gear ratio: 2.08 (27/13) 2.08 (27/13)
Dimensions
Recommended transom height S: 431 mm L: 558 mm
Weight with propeller (kg) F9.9JMHS: 40.0 kg, F9.9JMHL: 41.0 kg, F9.9JES: 42.0 kg F9.9JEL: 43.0 kg
Separate fuel tank capacity: 12 liters
Oil capacity: 0.8 liters
Additional features
Control: Tiller handle (MH), Remote control (E)
Lifting and trim (trim angles): Manual
Alternator: 12 V - 6 A *optional with rectifier/regulator ** 12 V - 6 A with rectifier/regulator
