MERCURY BRAND ENGINE TYPE F 50 ELPT EFI - F 50 ELPT EFI: 8254? - F 50 ELHPT EFI: 8324? 4 STROKE, INJECTION. SUPPLIED WITH PROPELLER. 5-YEAR WARRANTY....
MERCURY BRAND ENGINE TYPE F 50 ELPT EFI
- F 50 ELPT EFI: 8254?
- F 50 ELHPT EFI: 8324?
4 STROKE, INJECTION.
SUPPLIED WITH PROPELLER.
5-YEAR WARRANTY.
PRICE EXCLUDING TRANSPORT
ALSO AVAILABLE IN CT MODEL (CONTACT US FOR MORE INFORMATION)
HP / kW - 50 / 37
Engine type - 4 cylinder inline
Displacement (CID/CC) - 60.8 / 995
Maximum RPM - 5500-6000
Fuel induction system - Single overhead camshaft (SOHC) with 2 valves per cylinder
Alternator amperes/watts - 18 A / 226 watts
Recommended fuel - Unleaded 98 gasoline
Recommended oil - Mercury FourStroke Marine Oil 25W40
Engine protection warning system - SmartCraft Engine Guardian
Compatible with SmartCraft digital technology - Yes
Starting - Electric (key)
Steering - Compatible with Big Tiller / Tiller Kit / Remote Control
Shaft length - 20" / 508 mm
Gear ratio - 1.83:1
Dry weight *Lightest available model - 112 kg
CARB star rating - 3
Bore and stroke - 2.56 x 2.95" / 65 x 75 mm
Ignition - ECM 70
Fuel system - Electronic Fuel Injection (EFI)
Cooling system - Water-cooled with thermostat
Shift pattern - F-N-R
Mounting options - Standard
Trim system - Hydraulic lift
Exhaust system - Through propeller
Shallow water trim range (degrees) - 20
Optional external fuel tank - Yes
Color - Phantom Black
Lubrication system - Wet sump
Smoothness and performance: Their compact single overhead camshaft design and long piston stroke give Mercury FourStroke 40 - 60 hp outboards more low-end torque for excellent acceleration even when pushing a heavy load.
Large displacement, long stroke, four cylinders, single overhead camshaft guarantee optimal power and smooth navigation with the Command Thrust models.
Butterfly screw clamp: The 40 hp model with manual start, long shaft (20"/508 mm) and tiller steering is also available with a butterfly screw clamp. This clamp reduces the time and effort needed to remove or install the outboard on the boat’s transom.
The Big Tiller: The optional center-mount Big Tiller offers optimal control. A longer tiller handle integrates a convenient trim button, the shift lever is within easy reach, and an optional digital trolling control allows reducing engine speed down to 700 RPM in 10 RPM increments.
Instant starts / energy efficiency: Mercury’s Electronic Fuel Injection (EFI) ensures reliable instant starting, greater fuel efficiency, immediate throttle response, and protection against fuel quality issues.
Charging system: A high-output 18-amp alternator keeps batteries charged and fishing electronics running.
